| Machine Capacity | |
| Component Diameter | 5 mm – 150 mm |
| Grinding Diameter | 5 mm – 100 mm (Component Dependent) |
| Length of Grinding | 500 mm (Component Dependent) |
| Lead Range | 0 – 300 mm |
| CNC Control | |
| CNC Type | Siemens 840 DSL |
| HMI | Sinumerik Operate + Matrix Interface |
| Servo System | Sinamics S120 (Digital) |
| X Axis (Diameter) | |
| Slide Travel | 290 mm |
| Traverse Speed | 0 – 7 m/min (Digital Servo) |
| Including Linear Scale | Dual Position Feedback System |
| Z Axis (Length) | |
| Slide Travel | 540 mm |
| Traverse Speed | 0 – 7 m/min (Digital Servo) |
| Including Linear Scale | Dual Position Feedback System |
| C Axis (Work Head) | |
| Torque | 46 Nm |
| Traverse Speed | 0.4 – 120 RPM (Digital Servo) |
| Rotary Encoder | Dual Position Feedback System |
| Wheel Head | |
| Grinding Spindle Power | 8.8 kW @ 2000 RPM (Integrated Motor) |
| Programmable Speed | 500 – 2500 RPM (Digital Servo) |
| Wheel Balance System | Built-in Dynamic Balancing System |
| Standard Wheel Size | 13 mm or 25 mm |
| Helix Angle | Programmable ±45° |
| Dressing System | |
| Work Head Mounted | Fixed (Adjustable as Option) |
| Dresser Speed | 0 – 6000 RPM (Bi-directional) |
| Feed Rate | Programmable / Macro Calculated |
| Media | Disk / Roll / Single Point Diamond |
| Coolant System | |
| Capacity | 650 L (Standard) |
| Features | Temperature Control, Separator, Centrifuge |
| Machine Characteristics | |
| Approx. Gross Machine Weight | 6500 Kg |
| Approx. Floor Area | 3.4 m × 3.8 m (With Coolant System) |
Note: Specifications are subject to change without notification
