| Machine Capacity | |
| Component Diameter | 50 – 300 mm |
| Grinding Diameter | 8 – 200 mm (Component Dependent) |
| Length of Grinding | 100 mm (Component Dependent) |
| Lead Range | 0 – 300 mm |
| Work Holding Options | Face Plate / Precision Chuck / Fixture |
| CNC Control | |
| CNC Type | Siemens 840 DSL |
| HMI | Sinumerik Operate + Matrix Interface |
| Servo System | Sinamics S120 (Digital) |
| X Axis (Diameter) | |
| Slide Travel | 310 mm |
| Traverse Speed | 0 – 7 m/min (Digital Servo) |
| Including Linear Scale | Dual Position Feedback System |
| Z Axis (Length) | |
| Slide Travel | 500 mm |
| Traverse Speed | 0 – 7 m/min (Digital Servo) |
| Including Linear Scale | Dual Position Feedback System |
| C Axis (Work Head) | |
| Torque | 154 Nm (Direct Drive Torque Motor) |
| Traverse Speed | 0.4 – 120 RPM (Digital Servo) |
| Rotary Encoder | High Precision Feedback System |
| Wheel Head | |
| Grinding Spindle Power | 10 kW (Grinding Spindle Cartridge) |
| Programmable Speed | 5000 – 30,000 RPM (STD) (Digital Servo) |
| Helix Angle | Programmable ±20° |
| Dressing System | |
| Work Head Mounted | Fixed (Adjustable as Option) |
| Dresser Speed | 0 – 6000 RPM (Bi-directional) |
| Feed Rate | Programmable / Macro Calculated |
| Media | Disk / Roll / Single Point Diamond |
| Coolant System | |
| Capacity | 650 L (Standard) |
| Features | Temperature Control, Separator, Centrifuge |
| Machine Characteristics | |
| Approx. Gross Machine Weight | 6500 Kg |
| Approx. Floor Area | 3.4 m × 3.8 m (With Coolant System) |
Note: Specifications are subject to change without notification
